What Are Context-Based Redirections?

Context-Based Redirections is a Preview feature in Azure Virtual Desktop that lets you control peripheral and device redirection — clipboard, drives, printers, USB — based on the compliance state of the connecting device, rather than applying a blanket allow or deny for all users.

Instead of a binary on/off toggle on the host pool, you map an Entra ID Authentication Context to a redirection type. A Conditional Access policy then evaluates whether the connecting device is Intune-compliant. Compliant devices get the redirection; non-compliant or BYOD devices do not.

How It Works — The Three-Layer Model

The feature works across three separate Azure / Microsoft 365 control planes, each configured independently:

Prerequisites

# Install required modules (one-time)

Install-Module Microsoft.Graph -Scope CurrentUser -Force

Install-Module Az.DesktopVirtualization -Scope CurrentUser -Force

Step 1 — Create the Authentication Context

An Authentication Context is a named signal within Entra ID (ID c1 through c25) that Conditional Access policies can target. Think of it as a label you attach to a resource request, which CA then evaluates against your policies.

Script: New-AVDAuthenticationContext.ps1

What the script does

• Connects to Microsoft Graph with Policy.ReadWrite.ConditionalAccess scope
• Checks if the context ID is already in use and offers to update it
• Creates the authentication context with IsAvailable = $true (equivalent to checking Publish to apps in the portal)
• Disconnects cleanly on exit

Key Graph API call

$params = @{

Id = $ContextId

DisplayName = $DisplayName

Description = $Description

IsAvailable = $true # Publishes the context to apps

}

New-MgIdentityConditionalAccessAuthenticationContextClassReference `

-BodyParameter $params

Usage

.\New-AVDAuthenticationContext.ps1 `

-DisplayName "AVD Compliant Device" `

-Description "Requires compliant device for AVD clipboard/drive/USB/printer redirection" `

-ContextId "c1" `

-TenantId "xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx"

Step 2 — Create the Conditional Access Policy

The CA policy is what enforces the compliance requirement. It watches for authentication attempts that carry the context ID from Step 1 and grants access only if the device is marked compliant by Intune.

Script: New-AVDConditionalAccessPolicy.ps1

What the script does

• Connects to Microsoft Graph with Policy.ReadWrite.ConditionalAccess and Group.Read.All
• Validates the authentication context from Step 1 exists and is published
• Resolves Entra group display names to Object IDs automatically — no manual GUID lookup
• Builds the policy body targeting the auth context (not a cloud app)
• Defaults to enabledForReportingButNotEnforced — safe for initial testing
• Detects duplicate policy names and warns before creating

Key CA policy structure

$policyBody = @{

displayName = $PolicyName

state = $PolicyState

conditions = @{

applications = @{

includeAuthenticationContextClassReferences = @($ContextId)

}

}

grantControls = @{

operator = "OR"

builtInControls = @("compliantDevice")

}

}

New-MgIdentityConditionalAccessPolicy -BodyParameter $policyBody

Usage

.\New-AVDConditionalAccessPolicy.ps1 `

-TenantId "xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx" `

-PolicyName "AVD - Require Compliant Device for Redirection" `

-ContextId "c1" `

-TargetGroupName "AVD-Users" `

-ExcludeGroupName "CA-BreakGlass-Exclusion" `

-PolicyState "enabledForReportingButNotEnforced"

Step 3 — Configure Host Pool RDP Properties

The final step writes the dynamic context mapping into the host pool’s customRdpProperty string. This is what tells the AVD gateway to trigger the CA evaluation using the auth context when a user connects and attempts a redirection.

Script: Set-AVDHostPoolRdpAuthContext.ps1

RDP property format

The dynamic context RDP properties follow this format:

# Dynamic context RDP property format

redirectclipboard:dynamicContext:c1:

redirectdrives:dynamicContext:c1:

redirectprinters:dynamicContext:c1:

usbdevicestoredirect:dynamicContext:c1:

What the script does

• Fetches the current customRdpProperty string from the host pool
• Backs it up to a timestamped .txt file before touching anything
• Parses the existing RDP string into a hashtable — never overwrites unrelated RDP properties
• Removes conflicting static properties (e.g. redirectclipboard:i:1) that would conflict with dynamic mode
• Adds or updates only the targeted redirection types
• Detects if no changes are needed and exits cleanly
• Supports -WhatIf to preview changes without applying

Usage

# All four redirections

.\Set-AVDHostPoolRdpAuthContext.ps1 `

-SubscriptionId "xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx" `

-ResourceGroupName "rg-avd-prod" `

-HostPoolName "hp-avd-prod-01" `

-ContextId "c1"

# Selective redirections only

.\Set-AVDHostPoolRdpAuthContext.ps1 `

-SubscriptionId "xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx" `

-ResourceGroupName "rg-avd-prod" `

-HostPoolName "hp-avd-prod-01" `

-ContextId "c1" `

-Redirections Clipboard, Drive

# Preview changes without applying

.\Set-AVDHostPoolRdpAuthContext.ps1 ... -WhatIf

Orchestrator — Run All Steps from One Command

Rather than running three scripts independently and managing dependencies between them, the orchestrator drives all three steps from a single JSON parameter file. It handles module checks, connections, step dependencies, and prints a final pass/fail summary.

Script: Invoke-AVDContextBasedRedirections.ps1

Parameter file — avd-cbr-params.json

{
  "TenantId": "xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx",
  "SubscriptionId": "xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx",
  "AuthContext": {
    "ContextId": "c1",
    "DisplayName": "AVD Compliant Device",
    "Description": "Requires compliant device for redirection"
  },
  "ConditionalAccessPolicy": {
    "PolicyName": "AVD - Require Compliant Device for Redirection",
    "TargetGroupName": "AVD-Users",
    "ExcludeGroupName": "CA-BreakGlass-Exclusion",
    "PolicyState": "enabledForReportingButNotEnforced"
  },
  "HostPool": {
    "ResourceGroupName": "rg-avd-prod",
    "HostPoolName": "hp-avd-prod-01",
    "Redirections": [ "Clipboard", "Drive", "Printer", "USB" ]
  }
}

Orchestrator features

Orchestrator usage

# Full run — all three steps
.\Invoke-AVDContextBasedRedirections.ps1

# Custom parameter file
.\Invoke-AVDContextBasedRedirections.ps1 -ParameterFile ".\prod-params.json"

# Preview all changes (no modifications applied)
.\Invoke-AVDContextBasedRedirections.ps1 -WhatIf

# Retry only Step 3 after a failure
.\Invoke-AVDContextBasedRedirections.ps1 -Steps 3

Validation — Testing Your Configuration

After all three steps complete, validate behaviour from both a compliant and a non-compliant device. This cannot be automated — it requires a live AVD session.

Script Inventory

Known Limitations (Preview)

Feature in Preview — verify before production use
